The CSD570 series is a series of Ultra-slim CAT7 U/FTP cables, which come available in a wide variety of lengths and colours. They offer reliable interconnections in various applications, ranging from general-purpose office computer systems to digital AV network systems. The ultra-slim construction with an outer diameter of only Ø 4.0 mm offers an elegant solution for office patch usage while guaranteeing the best possible space-saving and airflow in rack applications. The compact and snagless connector design and numerous variants and colours offer reliable connections and a clear overview when wiring racks for various applications or protocols.

The CSD560 series is a range of ultra-slim CAT6A U/UTP cables available in a wide range of lengths and colors. The ultra-slim design with an outer diameter of only Ø 3.2 mm offers an elegant solution for office use while ensuring the best possible space saving and air circulation in rack applications. The compact and kink-free connector design as well as numerous variants and colors offer reliable connections and a clear overview when wiring racks for different applications or protocols.

The CLS260-Cca series are 2-core installation loudspeaker cables compliant with the Cca standards of the Construction Product Regulation (CPR) regarding fire and flammability resistance in fixed installations, minimizing toxic smoke and providing optimal resistance to spreading fire. In addition to its outstanding fire properties, the outer jacket of the cabling is smooth and durable for easy installation and pulling. The stranding keeps the cable flexible and easy to handle. The cable can be used indoors, outdoors, or in humid environments.

The HDM19 can be connected to any length of PROCAB CONTRACTOR HDMI cable without soldering! The HDM800 connection tool & HDM860 or HDM865 guiding jigs are required to use these connectors. The cable simply needs to be stripped, inserted into the guiding pieces, compressed and attached to the connector shell in order to complete the installation. The connector is gold-plated and housed in a sturdy metal shell. The shell is closed using two screws.

The CLV315A is an active optical HDMI 2.1 cable, designed for transmission of the next generation of 8K video content. It is able to transmit resolutions up to 8K (7680 x 4320p) 4:4:4 at 60 Hz with a bandwidth of 48 Gbps via OM3 optical fiber technology, eliminating the possibility of electronic interference. It is backwards compatible with HDMI 2.0 and HDMI 1.4, guaranteeing an optimal and future proof solution for any kind of installation. The fixed and detachable HDMI connector enables you to easily detach and reattach this connector. This way the cable can be fitted through holes and straight tubes with diameters as small as 25 mm. Ready for future HDCP 2.3 content encryption, compatible with all current and emerging HDR standards (HLG, HDR-10 and HDR-10+, Dolby Vision, Perceptual Quantizer and SL-HDR-1) and compatible with eARC HD audio standard. The Semi-Lock™ feature of the HDMI connector increases the withdrawal force of the connector and avoids loose or unstable connections of the HDMI connectors, reducing unwanted signal loss or disconnections.

The PRA524 is a high quality loudspeaker cable constructed using the PLH425 cable and fitted with two Neutrik 4 pole speakON cable (NL4FXX-W-S) conductors. The cable consists of four 2.5 mm (13 AWG) thin and dense stranded conductors. The combination of thin and dense strands with high purity oxygen free copper and the flexible and solid PVC outer jacket makes it the perfect cable for various kinds of applications. The smooth outer jacket of 11 mm provides great ease of installation for fixed systems while having perfect rolling & unrolling performance for highly demanding Rental & MI applications. An attached shrink sleeve allows custom labeling for easy identification. The cable comes in different lengths from 1.5 meters to 20 meters.

The CSV210 series are slimline HDMI 2.0 cables available in lengths from 0.5m up to 5m. They are specially designed for reliable connections in professional installations and applications. The design, with an outer diameter of only Ø 4.5 mm, offers an elegant solution for use in the office when installing narrow installations behind TVs or ensuring the best possible airflow in rack applications. They are fully HDMI 2.0 compliant and can handle a bandwidth of up to 18 Gbps and resolutions of up to 4K @ 60 Hz 4:4:4. The Semi-Lock™ connector with gold-plated contacts guarantees reliability in all types of environments.

This cable is suited for all applications requiring a duplex fiber connection using ST/PC connectors. Such as when linking two AUDAC R2's or M2’s through fiber interconnection. Use a PROCAB FBS125/C coupler to connect two FBS125 cables for even longer fiber links. This cable features a LSHF (low smoke halogen free) outer jacket.

The CLD400 features a standard 5-DIN connector with a molded shell on both ends, especially designed for use with the Musical Instrument Digital Interface (MIDI) communication system. Applications include the latest MIDI patch bays, and interconnection between MIDI equipment and MIDI served musical instruments. It comes in lengths of 0.5 meters to 10 meters, providing solutions for all applications.

The PRA522 is a high quality loudspeaker cable constructed using the PLH225 cable and fitted with two Neutrik 2 pole speakON cable (NL2FXX-W-S) conductors. The cable consists of two 2.5 mm (13 AWG) thin and dense stranded conductors. The combination of thin and dense strands with high purity oxygen free copper and the flexible and solid PVC outer jacket makes it the perfect cable for various kinds of applications. The smooth outer jacket of 9 mm provides great ease of installation for fixed systems while having perfect rolling & unrolling performance for highly demanding Rental & MI applications. An attached shrink sleeve allows custom labeling for easy identification. The cable comes in different lengths from 1.5 meters to 20 meters.

The PMI224 is a high-quality microphone cable with a highly flexible outer jacket. This cable is made rigid, which allows you to roll it up, even at longer lengths effortlessly. Two 24 AWG (0.22 mm) conductors consisting of 12 copper strands with 0.15 mm thickness are surrounded by an 80-strand braided copper shielding with superior coverage. Combined with the thick and soft PVC outer jacket, this provides a flexible but solid feel while allowing it to withstand an extreme amount of bending cycles. Optimal signal transmission is guaranteed due to the low capacitance and use of high-purity copper, while the high-coverage shielding provides excellent immunity against interference. These features make the PMI224 perfect for use in professional stage & studio applications.

The VCR526A is a toolless RJ45 modular plug, designed for computer and AV networking. Fitted with a connection that features an unique toolless termination, allowing quick disconnection of network cables. The toolless, push-down contacts are suitable for both stranded and solid inner conductors. Each jack is color coded for both the EIA/TIA568 A and B standards making for a true plug-and-play installation. The VCR526 has 2 variants: the VCR526A/U is the unshielded variant and the VCR526A/S is the shielded variant.

The PROCAB PR Series offers you a twisted assembling cable in various colours. This series consists of a cable with 2 twisted wires, one wire is black and for the other wire you can choose out of nine colour. Those nine colours come from the resistance colour code and are : brown, red, orange, yellow, green, blue, purple, grey and white.This cable is very efficient in use when doing a 19 inch rack assembling or when you don’t have a lot of space for “bigger” cables. The cable is very reliable for your signal thanks to its good twisting that reduces the talkover between cables. The PR Series of PROCAB offers you a cable that cares about your assembling.

The CLA716 is fitted with a 3.5mm male jack stereo connector on both sides of the cable and constructed using the SIG144 cable. The easy to handle PVC jacket is excellent for fixed indoor and mobile applications. The inner conductors are fitted with a durable shielding. This gives an excellent protection against interference of all kinds such as electromagnetic fields produced by dimmers, electric motors or power cables. The SIG series cables are “all-round” signal cables which are suited for all kinds of applications where reliable signal transmission is needed. It comes in length:s of 0.75 meters to 15 meters, providing solutions for all applications.

The CLA600 is an instrument cable constructed using the MC205 cable and fitted with two mono jack connectors. The 26 AWG (0.12 mm) thin & dense stranded bare copper conductors are surrounded by a high coverage bare copper spiral shielding. The durable shielding gives an excellent protection against interference of all kinds, such as electromagnetic fields caused by dimmers, motors or power cables. The flexible jacket made of PVC and is easy to handle. It comes in length:s of 1,5 meters up to 10 meters, providing solutions for all applications.

Connection cable with a waterproof AWX5 5-pin terminal, for use with outdoor WX series, AXIR and HS121 loudspeakers. Available in several lengths and both black & white colour.

The ALS Series cables are parallel designed loudspeaker cables, based on CCA (Copper Clad Aluminum). This is a technology where an outer sleeve of copper is bonded to a solid aluminum core. The result is a cable with characteristics lying between those of copper cables and bare aluminum cables. It combines the advantages from two sides, such as solderability, lower weight and lower material cost than bare copper with the higher conductivity and higher strength than pure aluminum. The cable composition is made of 85% aluminum with 15% copper, this is combined with a highly flexible jacket made of PVC with polarity indication.

The VCR526A is a toolless RJ45 modular plug, designed for computer and AV networking. Fitted with a connection that features an unique toolless termination, allowing quick disconnection of network cables. The toolless, push-down contacts are suitable for both stranded and solid inner conductors. Each jack is color coded for both the EIA/TIA568 A and B standards making for a true plug-and-play installation. The VCR526 has 2 variants: the VCR526A/U is the unshielded variant and the VCR526A/S is the shielded variant.

The D-size Keystone adapter will fit any Keystone module into a D-size hole.

The VCK630 is a Keystone data adapter with a female USB 3.0 A to USB 3.0 B connector. The USB connectors are reversible in the module so that the preferred connection is on the front side. This compact standardized snap-in module can easily be implemented in 45x45mm connection plates, CAYMON CASY modules or D-size holes.

The VCL4FP is a 4-pole female speaker connector in a robust plastic housing.

The PROCAB VCL4MP is a professional 4 pole speaker male socket with solder cups, plastic housing in a universal D-size plastic body for panel mounting
