IP-JP4-TX-10 | IP-JP4-TX-10

IP-JP4-TX-10

Art.-Nr.: IP-JP4-TX-10

Netvio is reshaping professional AV applications by combining high-performance hardware with advanced, license-inclusive software. The british brand’s carefully curated portfolio includes premium AV distribution solutions—enabling complete, end-to-end solutions for a wide range of applications. Designed to simplify complex integrations, Netvio makes both installation and day-to-day operation more efficient. A key advantage is seamless compatibility with major third-party control systems, alongside the company’s own integrated platforms, NETVIO360, AppBuilder and NetvioGo. This dual approach guarantees maximum freedom of choice—whether incorporating Netvio into an existing ecosystem or deploying it as a fully standalone solution.

Overview

4K60 (4:2:0) AVoIP Dual Stream Encoder with video wall, KVM over 1GbE up to 100m (328ft)

Supporting resolutions up to 4K60 at 4:2:0, the JP4 Series is ideal for video-centric applications such as digital signage, hospitality, live events, and sports environments where smooth motion and frame rate are critical. For detail-focused environments, the system supports 4K30 at 4:2:2, ensuring crisp text, accurate graphics, and reliable performance in corporate, education, and control room installations.

Product Details

Dual 1Gb 4K HDR, 2K30 PoE Encoder
4K HDR video encoding not surpassing 850Mbs
ContentPlus+ 2K30 Low Bandwidth Real-time-stream-protocol (RTSP) including stereo audio
Connected device control via IR, RS-232-CEC
Indivdiual routing of video, audio, control & USB
Analog & Digital Audio outputs
Alternative audio content overlay
USB Type A connectivity for KVM peripheral device connection
Free-On-Board AV control system or drivers for traditional providers.
Configured through Netvio360 premium interface for fast deployment.

Audio & Video

HDMI2.0b 18Gb HDMI input signal

4K 30Hz 4:2:0 8bit HDR

up to HDCP2.2

3840x2160 30fps 4:2:0 8bit

not exceeding 850Mbs

1920x1080 30fps + LPCM 2.0 audio

960x580 30fps

ideal conference hubs, laptop & commercial display integration

3840x2160 60fps 8b 4:4:4

HDR10, HLG, HDR10+ & Dolby Vision

4K to 2K

1 video frame

LPCM 2.0/5.1/7.1CH, Dolby Digital/Plus/EX, Dolby True HD, Dolby Atmos DTS, DTS-96/24, DTS-EX DSD, DTS High Res, DTS-HD Master, DTS:X

from HDMI or Analog connectivity

Works with……

IP-JP4-CL-10 (Secure IP Terminal/Controller), IP-RK-10 (Rack), IP-SW-24P-10 (Network Switch), IP-SW-48P-10 (Network Switch), TS-13-10 (Touch Panel)

IP-JP4-60 (DNT) series products

Software & Control

discovery, configuration, security, management & routing

IR, RS-232 & CEC

Crestron, Control4, Savant, RTi, Elan & Q-sys

Onboard Netvio-Go-Control: a license-free app, provides a compelling alternative to traditional control systems. Tailored for a streamlined and less complex AV experience

Onboard IR & RS-232 ports with signal routing via control system

USB KVM

Approved Network Switches

Netvio IP-SW Series, Netgear AV Line, Cisco Catalyst, SG & CBS Series, Draytek P Series, Araknis 210, 310 Series, Cambium EX2000 & EX3000 Series and more layer 2 managed switches compatible

Electrical & Mechanical

CE, UKCA, FCC, RoSH

W: 205mm x D: 100m x H: 22mm

W: 255mm x D: 157mm x H: 77mm

500g

900g

IEEE 802.3af (10watts max per device)

32 ºF to 104ºF / -20 ºC to 60ºC

-4 ºF to 140ºF / -20ºC to 60ºC

30 Btu/hr nominal

Encoder or Decoder device, Wall mounting brackets, Phoenix connectors for RS-232 and audio and IR TX & IR RX Accessories
