NOBA8A | Black | NOBA8A/B

NOBA8A

Art.-Nr.: NOBA8A/B

Color: Black

It is what we experience through the senses that makes life meaningful. In fact, it can be said that through the qualities in speech and music we experience, we become familiar with the higher values of life. This is just one of the reasons why at AUDAC you will find a passion for sound. Each speaker, audio matrix or amplifier solution we develop expresses that same inspiration and quality that exceeds users’ expectations, making it no coincidence our success results from exploring new methods and ideas beyond conventional boundaries.

Overview

Compact active 8" bass cabinet

The NOBA8A is a compact 8" active bass cabinet which is characterized by an innovative & unique design. With its curved shape, made of 4 mm thick aircraft graded aluminum and its extremely powerful 8” woofer of 200 Watts, the NOBA8A is able to deliver an unheard low frequency response for its small woofer size. The perfect acoustic experience is guaranteed when the entire audio frequency spectrum is equally distributed.

The slick look of the NOBA8A allows it to be placed against a wall, on the ceiling or even underneath furniture, yet due to the unique composition of its parts, NOBA8 ensures a much better spreading of sound waves than other similar cabinets. It is loaded with a 8” high-performance woofer constructed with a Max power handling of 200 Watt, with an RMS rating of 100 Watt. The strength of this loudspeaker originates from a 2.4” voice coil which is allowed to extra long excursions, combined with a large magnet size. Displacements are precisely controlled by the low-loss suspension resulting in a superior linear behaviour.

NOBA8A’s integrated class-D amplifier provides an impressive clarity of 150 Watts for both of the top speaker outputs to ensure impeccable sound division. It uses AUDAC’s WaveDynamics™ technology, which allows the user to easily set up the optimal acoustic configuration. The user can simply load its preferred audio settings through NOBA8A’s integrated USB input. The baIanced input connections are connected using 3-pin terminal block connectors, while each high frequency output features two connectors. This allows you to connect up to 4 (8 Ohm) or 8 (16 Ohm) loudspeakers.

An included wall mounting bracket offers convenient mounting possibilities to any wall, while fixation to ceilings is possible through optionally available accessories. An optional 2.4 GHz remote control allows handheld control of NOBA's basic functionalities, even while hidden out of sight.

Product Details

Innovative & unique design
8" high-performance woofer
Countless mounting possibilities
Lightweight class-D amplifier
Satelite amplifier for complete set solutions (2.1)
WaveDynamics™ speaker & set configurations
Advanced DSP and loudspeaker management
USB connection for preset loading
High grade aluminum construction
Wall mounted bracket included
Colors: Black (RAL9004), White (RAL9003)

8" Bass reflex cabinet

200 W

100 W

83 dBm

108 dB

90 Hz - 350 Hz

45 Hz - 350 Hz

2 x 150 W (@ 4 Ω Stereo), 2 x 75 W (@ 8 Ω Stereo)

> 85 dB

> 100 dB

Class-D

8" ferrite with 2.4" voice coil

Input: 2x 3-pin Euroblock, balanced, Output: 4x 2-pin Euroblock

558 x 383 x 149 mm (W x H x D)

9.75 kg

Aluminium with plastic side covers

Mounting wall bracket

Black (RAL9004) (NOBA8/B), White (RAL9003) (NOBA8/W)

Wall mounting bracket
