Overview

2x 1150 W High-Performance Installation Amplifier

Designed for the fixed installation market, the high performance stereo T2000 features MC2 Audio’s complementary Class AB bipolar topology and the unique MC2 Audio current driven floating drive stage. T2000 delivers over 1150W into 4 ohms with both channels driven, and an 2300W in bridge mode.

Conventional analogue level controls help deliver the cleanest sound available coupled with ultra-high standards of reliability. The T-Series proprietary control and protection circuitry continuously checks for fault conditions including shorted outputs, DC on outputs, excessive temperature, and component failure. If such an event occurs the outputs are disconnected, saving expensive driver repair bills.

Sophisticated ‘side chain’ limiters prevent distortion and speaker damage but are out-of-circuit until the onset of clipping. The control circuitry provides full protection against inrush current limiting with delayed power on. Low noise vari-speed fans are utilized to minimize mechanical noise, making the T Series an ideal choice for live theatre. Optional internal crossover cards available.

Product Details

  • Stereo high-performance installation amplifier
  • 2x 1150 W at 4 ohms, 2300 W at ohms (bridged)
  • Designed for the fixed installations
  • Class AB bipolar topology
  • Low noise vari-speed fans
  • Low distortion limiters with automatic response times
  • Optional cross-over cards available.
  • Optional 50V/70V/100V-Transformers available.
  • Full 5-year warranty
Number of channels
2
Output Power (per channel)
625W / 8 ohms, 1150W / 4 ohms, 2100W / 2 ohms
Output Power (bridged)
2300W / 8 ohms, 4200W / 4 ohms
THD% (@1dB below max output)
< 0.008% (1 kHz), < 0.03% (20Hz to 20kHz)
Gain
32/36dB
Sensitivity (for max power)
+7.5/3.5dBu (1.8/1.2V)
Frequency Response
20Hz to 20kHz (+ 0/- 0.5dB)
Power supply
120/240VAC
Power Consumption
2.8 A
Dimensions
88(h) x 482(w) x 428(d) mm / 2U
Weight
20.4kg
